    Ultra-Low Pressure Energy Saving ES-8040UFR Low Fouling Reverse Osmosis RO Membrane Element with Low Silica fouling for process water treatment

    Ask Lasest Price
    Brand Name : Keensen
    Model Number : ES-8040UFR
    Certification : ISO9001, NSF61, Halal
    Payment Terms : L/C, T/T
    Delivery Time : 3-30 work days
    • Product Details
    • Company Profile

    Ultra-Low Pressure Energy Saving ES-8040UFR Low Fouling Reverse Osmosis RO Membrane Element with Low Silica fouling for process water treatment

    Ultra-Low Pressure ES-8040UFR Low Fouling Reverse Osmosis Membrane Element with Low Silica fouling


    Description
    The ES-8040UFR is a newly developed ultra-low pressure, low-fouling membrane element designed to enhance system efficiency and reduce energy consumption. It improves the membrane's resistance to fouling, ensuring reliable performance over time. This membrane is ideal for a wide range of applications, including industrial process water treatment, municipal wastewater treatment, surface water treatment, and groundwater treatment.

    Features

    • Low energy consumption
    • Strong fouling resistant
    • High stability and reliability

    1.Specifications

    Model

    Active Area

    ft2(m2)

    Feed Spacer Thickness(mil)

    Permeate Flow Rate GPD(m3/D)

    Stabilized Salt Rejection (%)

    Minimum Salt Rejection(%)

    ES-8040UFR

    400(37.2)

    34

    10500(39.7)

    99.6

    99.5

    2.Standard Test Conditions

    Solution

    Temperature

    (℃)

    pH

    Operating Pressure

    psi(MPa)

    Recovery

    (%)

    2000mg/L NaCl257.5-8.0150(1.03)15

    Individual flow rate may vary±15%


    3.Element Dimensions and Operating Limits

    ModelLengthDiameterPermeate Tube inner Diameter
    inchmminchmminchmm
    80404010167.92011.1228.5

    Maximum Operating Pressure


    600psi(4.13MPa)
    Operating Temperature Range0-45℃
    Maximum Water Flow Rate17.0m3/h(8040),3.6 m3/h (4040)
    Maximum Feed Silt Density Index (SDI15)5.0

    Free Chlorine Tolerance


    0.1mg/L
    pH Range,Continuous Operation3-10
    pH Range,Short-Term Cleaning1-13
    Maximum Element Pressure Drop15psi(0.1MPa)
